Thermal Management Systems for BESS
Monitor coolant temperature, flow, pressure, pump status, and leak detection across containerized liquid-cooling skids.
Measures: Flow · Pressure
Used in:Power Generation
1
Main coolant flow
Confirms water/glycol circulation and detects pump failure or restrictions.
Dwyer Series IEF Insertion Electromagnetic Flow TransmitterDwyer Series IEF insertion magmeter for 4 to 36 in pipes: 0–6 m/s, ±0.5% of reading at the calibrated velocity, analog, pulse and alarm outputs, BACnet/Modbus option.
Dwyer Series TDFS2 Thermal Dispersion Flow Switch (Non-Mechanical, Low Pressure Drop, Large Pipes)Measure Flow Above or Below User Set Flow Rate; Normally-Open & Normally-Closed NPN Outputs; LED Indication
Dwyer CP-CN-CT-CX Coolpoint Vortex Meter; Water & Glycol4-20mA, Solid State Relay Output; 316L SS & Brass Body; PEEK Sensor; FKM Seal
FLT93 Thermal Dispersion SwitchFCI FLT93 heavy-duty thermal dispersion flow and level switch with no moving parts, for liquids, gases and interfaces in process plants.
Dwyer Series V6 Flotect Mini size Flow Switch for 1/2" to 2" PipesDwyer V6 Flotect compact vane flow switch for liquids, gases and air in 1/2 to 2 in pipes: weatherproof and explosion-proof, up to 2000 psig.
2
Pump-discharge pressure
Monitors loop pressure and pump performance; a second transmitter at pump suction provides pump differential pressure.
Dwyer 626/628 SS316L Industrial Pressure TransmittersDwyer 626/628 industrial pressure transmitters with 316L stainless wetted parts: 626 ±0.25% or 628 ±1% full scale, 4-20 mA or voltage output, NEMA 4X.
Weiss LF442Z Liquid Filled Pressure Gauge, Zytel Nylon CaseWeiss LF442Z 4 in liquid-filled pressure gauge in a Zytel nylon case with 316 SS internals: ±1% (Grade 1A), vacuum to 10,000 psi.
Application data from the DwyerOmega Application Navigator ↗. Ronsor can help adapt it to your site.
