Process Vessels & Skids

Bioprocessing & Process Skids

Fluid delivery, pressure and temperature, pump protection and process control across single-use bioreactors and sanitary process skids in pharma and life science manufacturing.

Measures: Fluid delivery · Pressure and temperature · Pump protection · Process control · Vessel viewing

Used in:Pharmaceutical

Diagram of the measuring points in a bioprocessing & process skids

1 2 3 4 5 6 7

Click a number to jump to that measuring point. Conceptual view, not for installation design.

Process Fluid Flow

Insertion electromagnetic flow measurement on the skid supply line verifies media delivery rates to the bioreactor and supports batch totalization.

Dwyer Series IEF Insertion Electromagnetic Flow TransmitterAccurate & Reliable Fluid Velocity Measurement; Flow 0-20 ft/s (0-6 m/s); Current, Voltage, Pulse Outputs; Alarms; Optional BACnet & Modbus

Flow Control Valve

High-flow modulating control valve trims media and utility flow to the vessel, holding process set points across a wide turndown range.

Dwyer Series 2000VA-3000WA High-Flow Control Valves – 50:1 Rangeability – Brass, Iron, SSHigh‑Flow Control Valve; Balanced Cage for Precise Control

Pump Protection

Paddle flow switch on the pump discharge proves flow and interlocks the pump to prevent dry running and mechanical seal damage.

Dwyer Series FS2 Vane Flow Switch for Boilers & Heaters, Adjustable 1-8 in PipesVane Flow Switch for Boilers/Heaters; Reliable Low‑Flow Trip

Flow / Level Verification

Thermal flow and level switch provides no-moving-parts detection of flow loss or low level on sanitary and utility lines.

FLT93 Thermal Dispersion SwitchFCI’s FLT93 Series are the most popularly installed heavy duty thermal dispersion flow and level switches in the world. The reasons are simple; FLT93s were developed from more than 40 years of flow and level switch engineering and…

Process Control & Alarming

Panel-mounted digital temperature controller drives on/off control with alarm and Modbus reporting to the plant control system.

Dwyer 40T2 Digital Temp Controller, 999°F/537°C, ModbusDigital temp controller; RTD, TC, thermistor, current, voltage inputs; 3-digit LED; Modbus; Alarm; IP65

Sanitary Process Pressure

Rangeable sanitary pressure transmitter with local display monitors vessel and line pressure on the skid, supporting sterile filtration, transfer and CIP/SIP steps without dead legs.

Omega PX3005K Sanitary, Rangeable, Pressure Transmitters with DisplaySanitary/CIP pressure transducer; Meets 3-A standards for food, beverage, dairy, pharma; IP67 316 SS enclosure; 5-digit display

Vessel Viewing & Foam Monitoring

Sanitary process cameras view inside fermenters and bioreactors from the control room, watching liquid and foam level so antifoam can be dosed as needed.
